Xylan® Coatings

Xylan® Coatings are a family of fluoropolymer coatings designed for use on various types of OEM components and fasteners. Xylan®  fluoropolymer coatings are dry film lubricants that can be applied to most metals, plastics and ceramic castings to provide low-friction and nonstick properties.

Xylan Coating

Xylan® Coating provides:

  • Lubrication
  • Controlled friction
  • Wear resistance
  • Heat resistance
  • Nonstick coating
  • Release properties
  • Corrosion protection
  • Reduced break out torques

Benefits of Xylan®:

Xylan® Coatings solve many common problems created when the ideal material for use in industrial applications has the wrong surface properties. Parts made from materials with the optimum strength, weight and cost may corrode, seize or gall. Xylan® coatings provide a working surface, tailored to the application and customer specification.


Xylan® Coating Specifications Typical Result
Tensile Strength (ASTM D1708) 4000 - 5000 psi
Elongation (ASTM D1457) 50%
Impact Strength (ASTM D256) 13 ft - lb/in
Hardness (ASTM D2240) 60 - 90 HB (shore D)
Abrasion Resistance (Tabor) > 15 mg
Coefficient of Friction (ASTM D1894) .15 - .35 static
Dielectric Strength (ASTM D149) 1400 volts per mil
Use Temperature -100°F to 500°F max
Melting Point n/a
Thermal Conductivity n/a
Chemical Resistance (ASTM D543) Good
Salt Spray Resistance (ASTM B117) Excellent
Water Absorption (ASTM D570) < .03 %
Thickness .0008" - .002"
